Oilite® Thrust Washers

Oilite® Thrust Washers

Provides self-lubricating thrust surfaces, especially in applications where assembly does not lend itself to the use of a flanged bearing. Alternatively, they can provide a second thrust surface at the non-flanged end of a bearing.

In thrust applications PV should not exceed 0.36N/mm² x m/s. Surface velocity (m/s) calculated on mean diameter of thrust face and pressure (N/mm²) on total thrust area.

We also offer an in-house machining service for non-standard sizes for specific customer requirements.

*Only available as standard in imperial

Find a bearing

Measurements

inch
inch
inch

Matching Bearings

Material Part Number Inner Diameter Outer Diameter Thickness
Oilite® AW 04 07 01 0.25 0.4375 0.0625 Product Details
Oilite® AW 04 08 01 0.25 0.5 0.0625 Product Details
Oilite® AW 04 10 01 0.25 0.625 0.063 Product Details
Oilite® AW 06 10 02 0.375 0.625 0.125 Product Details
Oilite® AW 06 12 01 0.375 0.75 0.0625 Product Details
Oilite® AW 07 12 01 0.4375 0.75 0.0625 Product Details
Oilite® AW 08 14 02 0.5 0.875 0.125 Product Details
Oilite® AW 08 14 03 0.5 0.875 0.1875 Product Details
Oilite® AW 08 16 01 0.5 1 0.0625 Product Details
Oilite® AW 08 16 02 0.5 1 0.125 Product Details
Oilite® AW 08 16 03 0.5 1 0.1875 Product Details
Oilite® AW 09 18 01 0.5625 1.125 0.0625 Product Details
Oilite® AW 09 20 01 0.563 1.25 0.063 Product Details
Oilite® AW 10 16 01 0.625 1 0.0625 Product Details
Oilite® AW 10 16 02 0.625 1 0.125 Product Details
Oilite® AW 10 19 01 0.625 1.188 0.063 Product Details
Oilite® AW 10 19 05 0.625 1.188 0.094 Product Details
Oilite® AW 10 19 02 0.625 1.188 0.125 Product Details
Oilite® AW 10 20 01 0.625 1.25 0.063 Product Details
Oilite® AW 10 20 02 0.625 1.25 0.125 Product Details
Oilite® AW 11 20 02 0.6875 1.25 0.125 Product Details
Oilite® AW 12 20 01 0.75 1.25 0.063 Product Details
Oilite® AW 12 20 02 0.75 1.25 0.125 Product Details
Oilite® AW 12 22 01 0.75 1.375 0.0625 Product Details
Oilite® AW 12 28 01 0.75 1.75 0.0625 Product Details
Oilite® AW 13 24 02 0.8125 1.5 0.125 Product Details
Oilite® AW 14 24 02 0.875 1.5 0.125 Product Details
Oilite® AW 14 30 02 0.875 1.875 0.125 Product Details
Oilite® AW 16 24 01 1 1.5 0.0625 Product Details
Oilite® AW 16 28 01 1 1.75 0.0625 Product Details
Oilite® AW 16 28 02 1 1.75 0.125 Product Details
Oilite® AW 16 32 02 1 2 0.125 Product Details
Oilite® AW 16 46 02 1 2.875 0.125 Product Details
Oilite® AW 20 30 02 1.25 1.875 0.125 Product Details
Oilite® AW 20 38 02 1.25 2.375 0.125 Product Details
Oilite® AW 20 48 02 1.25 3 0.125 Product Details
Oilite® AW 20 48 04 1.25 3 0.25 Product Details
Oilite® AW 22 31 02 1.375 1.9375 0.125 Product Details
Oilite® AW 23 40 02 1.4375 2.5 0.125 Product Details
Oilite® AW 24 32 02 1.5 2 0.125 Product Details
Oilite® AW 26 38 02 1.625 2.375 0.125 Product Details
Oilite® AW 28 42 02 1.75 2.625 0.125 Product Details
Oilite® AW 32 48 03 2 3 0.1875 Product Details
Oilite® AW 32 48 04 2 3 0.25 Product Details
Oilite® AW 32 64 02 2 4 0.125 Product Details
Oilite® AW 36 56 02 2.25 3.5 0.125 Product Details
Oilite® AW 44 62 04 2.75 3.875 0.25 Product Details
